Specifications:
|
Size |
DN50-DN600 |
|
Nominal Pressure |
PN10/16, 150LB |
|
Working Temperature |
-30。c - 135。C |
|
Suitable Media |
Chemicals, air, water, steam, oil, acids, salts etc. |
Standards:
|
Face to Face |
EB1234/BS5143 |
|
Flange drilling |
DIN2501 PN10/16, ANSI 125/150, BS4504, JIS10K,EN1092 |
|
Test Inspection |
API598,DN3230 |
Material:
|
Body |
Cast Iron, Ductile Iron |
|
Disc |
Ductile Iron, Brass, Stainless Steel |
|
Stem |
Stainless Steel |
|
Bushing |
Brass, PTFE |
|
Spring |
SS304,SS316 |
|
O ring |
NBR |
|
Screw |
Steel |
